Description

These injectors flow 80 lbs/hr at 43.5 PSI ( 3 BAR ) and even more at greater PSI! In addition, these units are high-impedance. Despite the high flow rate, they are linear and controllable at low pulse widths and have been used in ULEV applications! This allows you to use a larger injector than normally possible without hurting idle and low speed driveability. Adding to the flexibility of application, these units are high-impedance; making them compatible with most ECUs, while delivering the most flow available in a High-Impedance injector.

These injectors are able to function at high fuel pressures and don’t exhibit the high fuel pressure handling problems found with many other high flow high-impedance injectors. This makes these injectors very well suited to turbocharged and supercharged applications that see high fuel system pressures.

Features:

Genuine, reliable Siemens Injectors

Excellent response characteristics

Robust Design

High Impedance

Low Impedance performance characteristics with High Impedance Compatibility

Specifications:

Static Flow Rate: 80lb/hr = 875 cc/min

Dynamic Flow Rate : 18.6 mg/pulse 2.5ms PW, 20 ms Period

Coil Resistance: 12 Ohms (This high-impedance injector will work with all factory ECM/PCM injector drivers)

Connector: Bosch EV1

Series: DEKA 4 ( DEKA IV )

O-Ring Type: Viton
