OVERVIEW
Our B&M Hi-Tek SuperCoolers feature a stacked plate design which is up to 30% more efficient than tube and fin designs and have 15% less flow restriction resulting in maximum cooling efficiency. The cooler features built-in attachment points, making mounting the cooler a breeze and the cooler is suitable for many fluids including transmission fluids, engine oil, and power steering fluid. This SuperCooler has a BTU rating of 20,500 BTU's. The hose fitting size for this cooler is 1/2-inch NPT and can be mounted with fittings located up, down or sideways. The SuperCooler features durable brazed aluminum construction and is pressure tested to 200 PSI. This cooler is recommended for heavy duty vehicles with V8 engines, full size trucks, vans and high performance applications.
Features:
- Better Than an Ordinary Tube and Fin Design Cooler
- Larger Size for High Performance Applications
- Stacked-Plate Design for Better Efficiency
- Stronger and More Resistant To Damage
SPECIFICATION
| Brand | B&M |
|---|---|
| BTU Rating | 20,500 |
| Color | Black |
| Core Design/Type | Stacked Plate |
| Core Material | Aluminum |
| Depth (in) | 1.5 |
| Design Type | Stacked Plate |
| Emission Code | 5 |
| Height (in) | 10 |
| Inlet Attachment Type | Female Threads |
| Inlet Size | 1/2 NPT |
| Low Temperature Bypass | No |
| Material | Aluminum |
| Outlet Attachment Type | Female Threads |
| Outlet Size | 1/2 NPT |
| Product Type | Automatic Transmission Oil Cooler |
| Row Quanity | 40 |
| Width (in) | 11.25 |
| UPC | 019695702663 |
| Part Number | 70266 |
